New Generation 2 Axis BGC 3.1 Brushless Gimbal Card Controller MOS Drive with Mini 6050 Sensor

2,200.00

Description

Specification of BGC 3.1
Brushless Gimbal Controller 3.1
mini USB connector (no FTDI needed)
stabilized VBUS (USB port)
optimized pin layout GND, A1 and A2 GND, multi-port, 5 V
L6234 brushless motor driver
2 outputs for brushless motors
4 receiver input
6 analog inputs
serial port available
power LED (blue)
small LEDs on USB
Dimensions 50mm x 50mm
Standard MK style mounting holes 45mm x 45mm
2 instead of 4 glass diodes SOT23
5V better stabilized
Shifter lever on the I2C Bus (3.3 V to 5 V)
reduced traction (for better edges)
MPU6050 3 Sensor
chip module : MPU-6050
Power supply: 3-5V
Gyroscope range: + 250 500 1000 2000 / s
Acceleration range: ± 2 ± 4 ± 8 ± 16g
Communication: Standard IIC communication agreement
Integrated chip 16-bit AD converter, 16-bit data output
Pin Pitch: 2.54mm
Size: 20.3mm x 16.5mm
Package List:
1 * Brushless Cardan Controller 3.1
1 * MPU6050 Sensor
1 * Cable</span
